WaterMate greywater recycling unit


Price:
$995 excl GST

Stock:
In stock

Description

The simple way to recycle greywater for garden irrigation. This regular version of our popular WaterMate can accommodate a maximum flow of 136LPM, sufficient for one drain in a residential home, like a kitchen or bathroom drain. To divert and recycle greywater from the entire house, see our large size WaterMate.

With the WaterMate you can

  • save money on watering your garden
  • save your septic system, if you have one, by diverting greywater from it
  • use water twice and return it to the environment, naturally

The WaterMate is part of Allflow's Total Water Solution: everything you need for your home's rainwater, greywater, and wastewater systems. We can supply all the equipment you'll need for these systems, including the WaterMate.

If you wish to send your filtered, cleaned greywater to an irrigation field to feed plants, shrubs, trees or veggies, buy our irrigation kit as well. It provides you all the hose, fittings, and tape you need to complete the project.

If you would like to connect a grease trap to your single-tap greywater filtration process, this grease trap will do the job.

How the WaterMate works

(See second image for diagram)

Step 1. When the valve is open, greywater flows directly to the mains sewage or septic tank.

Step 2. When the valve is closed, greywater from the house is diverted to the inlet of the filter.

Step 3. The greywater flows through the 1st filter web that retains major and medium particles such as hair, lint, paper detergent clogs and other impurities (The filter web: Black - Low density, Green - Medium density).

Step 4. The greywater flows through the 2nd filter web that retains medium and small particles (The filter web: Green - Medium density, Blue - High density)

Step 5. The greywater flows through the 3rd filter web that retains small and minor particles (The filter web: Blue - High density, Gray - Super high density)

Step 6. Filtered greywater is pumped to the irrigation.


The WaterMate comes with washable and replaceable filters and you can purchase new filters from Allflow.

Specifications

  • HP: 1/4
  • W: 200
  • mm: 25-32
  • Rated head: 5m
  • Rated flow: 53 LPM
  • Max head: 7m
  • Max flow: 136 LPM
  • Dimensions: 155mm L x 155mm W x 240mm H

Components diagramme

See third image for diagramme, key below:

A. Inlet (2”)
B. Diverting valve
C. Outlet to sewer (2”)
D. Basket
E. Overflow stand pipe
F. FSM190 Black
G. FSM290 Green
H. FSM365 Blue
I. FSM460 Grey
J. Water pump
K. Pump outlet
L. Electronic pump controller
M. Drain/Cleanout point with 1” plug
N. Kink-free hose and hose clamp
O. Outlet Connector
P. Outlet
Q. Tank Cover
R. Tank
S. Inlet cover
T. Electrical pump lead

For more information, download the WaterMate information sheet.
