DAB Euroinox 50/50 Pump

Multi-stage electric centrifugal pump with horizontal shaft and stainless steel pump body. Suitable for domestic use, water supply and pressurisation, irrigation of gardens and light industrial applications, and moving water in general.

Excellent suction capacity even in the presence of air bubbles, featuring extremely quiet operation.

Installation is either fixed or portable in a horizontal position.

Specifications

Liquid temperature range pumped: from 0 °C to +35 °C - Maximum ambient temperature: +40°C

Operating range: from 10 to 120 l/min. with a head of up to 72 m.

About the pump

Pump body is stainless steel and the motor support is die cast aluminium with seal holder cover in AISI 304 stainless steel. Carbon/ceramic mechanical seal. Rotor shaft in AISI 304 stainless steel. Impeller and diffuser bodies and diffuser in technopolymer. Stainless steel wear ring.

About the motor

Asynchronous, continuous service motor. Incorporated thermo-amperometric protection and permanently inserted capacitor in the single phase version. Overload protection to be provided by the user for the three-phase version.
